उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| प्रतिरूप संख्या।: | UL21410 | म्यान सामग्री: | एक्स एल पी ई |
|---|---|---|---|
| इन्सुलेशन सामग्री: | पीवीसी, पीई, एक्सएलपीई | सामग्री आकार: | गोल तार |
| मात्रा/रोल: | 305 मीटर, 610 मीटर या अनुरोध के रूप में | रेटेड तापमान: | 125 डिग्री सेल्सियस |
| रेटेड वोल्टेज: | 300V | कंडक्टर प्रकार: | टिन्ड या नंगे तांबा, फंसे या एकल कंडक्टर |
| शील्ड प्रकार: | टिनडेड या नंगे तांबे के तार, सर्पिल या ब्रैड शील्ड या अल-मिलर लिपटे ढाल | जैकेट सामग्री: | एक्स एल पी ई |
| अधिकतम कंडक्टर प्रतिरोध: | 223//किमी (28 AWG के लिए) | कंडक्टर आकार: | 28 AWG से 22 AWG |
| इन्सुलेशन मोटाई: | 0.26 मिमी | नॉमिनल डायामीटर: | 0.80 मिमी से 6.00 मिमी |
| कोर वायर नंबर: | 2C-50C (वैकल्पिक) | ||
| प्रमुखता देना: | UL21410 XLPE insulated wire cable,industrial control flexible cable,305m roll XLPE cable |
||
| Attribute | Value |
|---|---|
| Model NO. | UL21410 |
| Sheath Material | XLPE |
| Insulation Material | PVC, PE, XLPE |
| Material Shape | Round Wire |
| Range of Application | Industrial Control |
| Brand | Hwatek |
| Color | Optional |
| Qty/Roll | 305m, 610m or as Request |
| Transport Package | Rolled in Reels, Packed in Pallets |
| Trademark | Hwatek |
| Origin | China |
| HS Code | 8544492100 |
Products are used in communication equipment, instruments, industrial control systems, electronic and electrical equipment.
Internal wiring or external interconnection of electronic equipment.
UL758 & UL1581 & CSA C22.2 No.210
Rated temperature: 125ºC
Rated Voltage: 300V
| Product Number | Conductor | Insulation | Shield | Jacket | Max. Cond. Resistance (200C) Ω/km |
|---|---|---|---|---|---|
| HT21410**101 | 3C | 28 | 7/0.127 | 0.38 | 0.26 | 0.80 | 0.025 | 0.10 | 0.80 | 3.80 | 223 |
| HT21410**102 | 3C | 26 | 7/0.16 | 0.48 | 0.26 | 0.90 | 0.025 | 0.10 | 0.80 | 4.04 | 140 |
| HT21410**103 | 3C | 24 | 11/0.16 | 0.60 | 0.26 | 1.12 | 0.025 | 0.10 | 0.80 | 4.51 | 87.6 |
| HT21410**104 | 3C | 22 | 17/0.16 | 0.76 | 0.26 | 1.30 | 0.025 | 0.10 | 0.80 | 4.90 | 55.4 |
| HT21410**105 | 6C | 28 | 7/0.127 | 0.38 | 0.26 | 0.80 | 0.025 | 0.12 | 0.80 | 4.70 | 223 |
| HT21410**106 | 6C | 26 | 7/0.16 | 0.48 | 0.26 | 0.90 | 0.025 | 0.12 | 1.00 | 5.30 | 140 |
| HT21410**107 | 6C | 24 | 11/0.16 | 0.60 | 0.26 | 1.12 | 0.025 | 0.12 | 1.00 | 6.00 | 87.6 |
Remark: Optional core wire number 2C-50C, and shielding way
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
A: We produce consumer electronics wires, hook up wires, industrial cables, robot cables, EV charging cables, new/green energy cables.
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
A: Yes, we are willing to arrange samples for you.
A: Normally we can finish your orders in 2-3 weeks, and 5-6 weeks in peak season.
A: Always a pre-production sample before mass production and final inspection before shipment.
